Description
Features:
- 2.1MP/1080p 1/2.8” image sensor at real-time 30fps.
- 2.3mm fixed lens with wide coverage FoV for full entrance view.
- True Wide Dynamic Range (WDR) for clear images in challenging light.
- Simultaneous streaming and multiple codec options for smart bandwidth management.
- 1-10’ Smart IR™ range with intelligent camera sync for clear B/W images with no need for external light.
- 1-3’ white light LED range for deterrence and color images in low-light.
- Person detection for intelligent alarm and recording management.
- Video tampering detection and alarm with scene change, blur and abnormal color detection.
- Noise suppression and echo cancellation for clean two-way audio communications.
- Smart DNR™ 3D digital noise reduction reduces noise and ghosting for motion in low-light environments.
- Privacy zones cover sensitive areas in the camera’s field of view.
- Backlight compensation (BLC) adjusts the camera’s exposure settings to compensate for strong backlight in a scene.
- Two-way audio with built-in microphone and speaker for direct communication between the monitoring station and the camera’s location.
- Local SD card slot for local recording in case of network loss.
- Alarm sensor input and door lock output for access control integration.
- Web server built-in for easy camera management from any browser.
- PoE and DC12V for single cable simplified installation.
- NDAA-compliant for federal and government projects.
- IP65-rated housing is dust-proof and protected against water jets.
- 5 year warranty
Technical Specifications
Color temperature
- 5600K
- Cold light
WL wavelength (lumen)
34.1lm
Image sensor
2.1MP/1080p 1/2.8" CMOS sensor
Maximum resolution
2.1MP/1080p
Minimum Scene Illumination in color
0.0038 lux (color)
Total Pixels
1920 (H) x 1080 (V)
Focal Length
2.3mm
Horizontal Field of View (HFOV)
139°
Illumination Distance
- 1ft - 10ft (0.3 - 3m) range
- 1ft - 3ft ( 0.3 - 1m) range
Lens Type
Fixed Lens
Vertical Field of View (VFOV)
74°
Audio compression
G.711A / U
I/O Alarm in/out
- 1 door lock output (1A 125VAC / 1A 24VDC)
- 1 input
I/O Audio in/out
- 1 microphone built-in
- 1 speaker built-in
LED Indicator
- Blue: Wi-Fi Setting Mode
- Flashing Blue: Doorbell Button Pressed
- Flashing Green: System Update
- Green: Standby Mode at Night
- White
3D digital noise reduction
Smart DNR™ 3D Digital Noise Reduction
Gain control
Auto
Backlight compensation (BLC)
Yes
Camera Analytics
- Person Detection
- video Tampering Detection (Scene Change
- Video Blur
- Abnormal Color Detection)
Day and night
- Auto day/night
- Day (color)
- Night (B/W)
LPR Capture Range
Wall Mounted Intercam
Memory slot
- Micro SD/SDHC/SDXC class 10 card (card not included)
- Up to 1TB micro SD / FAT32
Operational Notifications
- Alarm output activation
- HTTP action
- Recording
- SD card recording
Shutter Mode
- Auto
- Manual
Shutter Speed
1/2s ~ 1/100000s
Wide Dynamic Range (WDR)
True WDR 120dB
Bitrate Control
- Multi-streaming CBR/VBR at H.264
- H.265 (controllable frame rate and bandwidth)
IP
- IPv4
- IPv6
LAN
802.3 compliance 10/100 LAN
Network resolution
- 2.1MP/1080p
- 720p
- D1
Network Web Viewer
- Google Chrome® browser
- Linux® OS
- Mac® OS
- Microsoft Edge® browser
- Mozilla Firefox® browser
- Safari® browser
- Windows® OS
Protocol
- 802.1x
- DDNS
- DHCP
- FTP
- HTTP
- HTTPs
- NTP
- ONVIF
- QoS
- RTSP
- SMTP
- UDP
- UPnP
Security
- Digest authentication (ID/PW)
- IP filtering
- MAC filtering
- Multi-user authority
- SSL/TSL
Streaming Capability
Dual-stream at different rates and resolutions
Video Compression Type
- H.264
- H.265
- MJPEG
Video Management Software
- Any ONVIF conformant CMS
- DW Spectrum® IPVMS
Compliance
- CE
- FCC
- NDAA
Environmental Operating Humidity
0-95% RH (non–condensing)
Environmental Operating Temperature
-4°F ~ 122°F (-20°C ~ 50°C)
Power Consumption
- DC12V: max 6.0W
- 500mA
- PoE: max 6.0W
Power Requirements
- 12V DC
- Adapter not included
- PoE
Materials
- Anti-Tamper Interface
- Doorbell Button
- Plastic
IP rating
Dust-Proof and Water Jets Resistant (IP65)
Housing Color
Black
Camera Weight
0.31 lbs (0.145kg)
Camera Dimensions (H X W X D)
5.9” x 1.96” x 1.17” (150 × 50 × 29.8mm)
Warranty
5 Year Warranty
Warranty
5 Year Warranty
