Description
The 500' long Beige Genesis Series 22 AWG Unshielded Multi-Conductor Cable with 4 Unpaired Conductors from Honeywell comes in a speedbag packaging. It is a non-twisted cable with 4 unpaired conductors. The cable offers a gauge size of 22 AWG. It is unshielded and features a general-purpose jacketing material. Applications for these cables include control cables (Lutron systems and Crestron systems), alarms, intercoms, speakers, and other low-voltage circuits that are power limited.
Features:
- High Signal Integrity
- Flexible Installation
- Durable Sunlight-Resistant Jacket
- UL/ETL Compliance
- Wide Application Range (Alarm/Intercom/Audio)
- Countdown Footage for Fast Measuring
Technical Specifications
Color
Beige
Cable Length
500ft
Package Type
Coil
American Wire Gauge
22AWG
Conductor Type
Solid Bare Copper
CAT
CM/CL2
Jacket Type
PVC
Shield Type
Unshielded
Voltage
300V
Number of Conductors
4
Impedance
81Ohms
DC Resistance
18Ohms/1000ft. at 20 °C
Compliance
- UL1685
- ETL
- CM
- CL2
- FCC
Cable Type
General Purpose Cable
