Description
The Accutech 3101 Magnetic Lock is custom-designed to our specifications and cannot be purchased directly from the manufacturer. The 3101 Magnetic Lock will engage when the zone Controller detects a Tag in the Tx Activation Field. The Lock will remain engaged as long as the Tag is in the Tx Activation Field. When the Tag leaves the Tx Activation Field, the Lock will disengage after an adjustable period of time (0-120 seconds).
Features:
- The Lock will NOT engage (or will disengage) when the facility’s Fire Alarm is activated or power is lost.
- An audible tone enunciates both countdown and release.
- When the Lock releases, the red LED will turn solid green and the alarm will sound continuously.
Technical Specifications
Voltage

										12VAC/DC



































Current

										300mA

Gauge

										18



































Number of Conductors

										6

Finish

										Satin Aluminum-US28



































Operating Temperature

										32º to 120º F
