Description
The Diamond Series is a full portfolio of solutions composed of project-oriented products including IPC, NVR, PTZ, XVR, Thermal and software platform which adopts industry-leading deep learning algorithms. Focusing on customer’s requirements, this series provides precise, reliable and comprehensive AI solutions for verticals.
Features:
- 5MP, 1/2.7" CMOS image sensor, low illuminance, high image definition
- Outputs max. 5MP (2592 × 1944) @25/30 fps
- H.265 codec, high compression rate, ultra-low bit rate
- Built-in efficient IR illuminator, and the max. illumination distance: 10 m
- ROI, SMART H.264 /H.265 , flexible coding, applicable to various bandwidth and storage environments
- 120dB WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Technical Specifications
Imaging Device
1/2.7”Progressive Scan CMOS
Megapixel
5MP
Resolution
2592×1944
Shutter Speed
- Auto/Manual 1/3 s ~ 1/100
- 000 s
S/N Ratio
> 56dB
Focal Length
1.4mm
Video Compression
H.265/H.264/H.264H/H.264B/MJPEG
Wide Dynamic Range
120dB
Ethernet Port
RJ-45 (10/100 Base-T)
Voltage
12VDC
Operating Temperature
-10°C ~ 50°C (14°F ~ 122°F)
Operating Humidity
≤ 95% RH
Material
- Metal
- Plastic
