Description
Smart managed switches are developed by Hikvision, featuring easy management and maintenance. You can easily deploy, monitor and expand your security system anytime and anywhere with our software platforms. You can view the network topology, monitor the health of the network and receive device alarms in real time, which greatly reduces the cost of network operation and maintenance.
Features:
- 8 × gigabit PoE ports, and 2 × gigabit fiber optical ports.
- IEEE 802.3at/af standard for PoE ports.
- Network topology management, alarm push, network health monitor.
- 6 kV surge protection for PoE ports.
- AF/AT camera can reach up to 300 m in extend mode.
- PoE watchdog to auto detect and restart the cameras that do not respond.
Technical Specifications
Material
Metal
Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity
5% to 95% (no condensation)
Voltage
48VDC
Current
2.5A
Consumption
120W
Surge Protection
6 kV
Compliance
- FCC (47 CFR Part 15
- Subpart B);UL (UL 60950-1);CE-RoHS (201165EU)
Ethernet Port
- IEEE 802.3af
- IEEE 802.3at
