ezEX-RJ45(38) Pass-Through RJ45 Connectors, CAT5E Unshielded- 50pcs in Clamshell - 100047C

The patented ezEX38 connectors feature a unique integrated Hi-Lo stagger load bar and allows big’ conductors to pass through the front end of the connector making it easy to verify the wiring sequence before terminating. These connectors are used with Cat5e (Sm. Cat6) cabling and is recommended for PoE/PoE+ and Data applications. These connectors are also available in shielded (STP) internal ground style. The termination tool for these connectors is the EXO Crimp Frame and EXO-EX Die (100061C).

Features:

• ezEX-RJ45 (ezEX38 series) pass-through RJ45 connectors
• ezEX38 connectors are designed for cables with 0.033" – 0.038" (0.84 – .97mm) insulation diameter
• Unshielded
• Package includes 50 pieces
• Retail-ready clamshell packaging
• 0.290” (7.36mm) max cable outer diameter
• 0.033” – 0.038” (0.84 –0.97mm) max insulation diameter (conductors)
• Compatible with solid or stranded 24 - 22AWG twisted pair cable
• 50 micron gold plated contacts
• Hi-Lo stagger to isolate each conductor
• Simple one piece/pass through design does not require bars or liners
• TAA, TIA, RoHS, UL & FCC compliant
• US Patents 9,543,729 B2; 10,116,082 B2; & 10,573,990 B2. Foreign patents.
• Rated for data and PoE applications
• Recommended crimp tools: 100061 or 12520
