Description
1-3/4in Narrow SS Wall Plate, DPDT Alternate Action, Red & Green LEDs
Features:
- Stainless steel wall plate accepts standard 1-1/8in mortise cylinder
- Tamper-proof and slotted head screws included
- Mortise Cylinders not included, available separately (CY-1, CY-1A)
- Momentary or alternate switch
- SPDT or DPDT
- No LED, green LED, green and red LEDs,
Technical Specifications
Switch Form
DPDT
Action Type
Alternate
Plate Width
1.75in (narrow jamb)
Material
Stainless steel
Finish
Satin / brushed stainless steel
Contact Rating
4 A @ 28 V DC
LED Support
12 or 24 V AC/DC
Switch Depth
1.25in
Switch Leads
Colored leads
Cylinder Fit
1?in–1¼in (use spacer for 1¼in)
Tamper Hardware
- Slotted
- tamper-proof screws
Temp Range
+15 °F to +120 °F
Warranty
Limited Lifetime Warranty
