Description
Pneumatic Time Delay, One N/O and One N/C Contact, PUSH TO EXIT, Black Fill, Satin Aluminum
Features:
- PN 1-7/8" narrow stile plate is suitable for mullion mounting
- PT T-Style plate mounted on standard single gang electrical box
- PS Single gang plate mounted on standard single gang electrical box
- PD Mounts on standard double gang electrical box
- Machined from solid aluminum with engraved text and anodized finish
- Tamper resistant mounting
Technical Specifcations
Series
- PD
- PN
- PS
- PT push plates
Switch Type
Pneumatic time delay (2–60 s)
Contact Rating
4 A @ 28 V DC (or 10 A @ 35 VDC/120 VAC per some sources)
Mounting
- Narrow stile (PN) fits mullion
- T-Style (PT)
- others single/double gang
Material
Machined from solid aluminum
Finish
Clear anodized (aluminum)
Legend
- PUSH TO EXIT engraved
- black fill
Vandal Resistant
- Yes
- tamper-resistant mounting
Compliance
UL and C-UL listed
NFPA-101
Compliant
UL-294 Listing
Yes
Finish Options
Multiple finishes available
Warranty
Limited Lifetime Warranty
Warranty
Limited Lifetime Warranty
