Description
Double Gang, Stainless Steel Wall Plate, Four DPDT, Momentary, Green Illuminated Push Button, 12/24 VAC/VDC, with Four 1/2in Red LED
Features:
- Narrow activation zone is limited to door handle area (range 28" to 48")
- Designed to eliminate cross-traffic activation
- Cannot be deceived by placing objects under door
- Adjustable time delay from 1 to 60 seconds
- Built-in buzzer, can be silenced if required
- Request to exit input, keypad or card reader input
Technical Specifications
Sensor Type
Active focused infrared
Power Input
- 12/24 VAC/DC
- auto-detect
Current Draw
- 155 mA (no buzzer)
- 200 mA max
Relay Type
DPDT (2 Form C)
Contact Rating
- 2 A @30 VDC/24 VAC
- 1.3 A nominal
Size
6.875in × 1.875in × 2in (175×48×51 mm)
Material
Black anodized aluminum + ABS
Finish
Black anodized aluminum
Operating Temp
0–49 °C (32–120 °F)
Humidity Rating
- 0–93% ULC
- 0–85% UL
Warranty
Limited Lifetime Warranty
Certifications
- UL-294
- CAN/ULC-S319
Warranty
Limited Lifetime Warranty
