TOA Electronics

SKU WT-5800 H01US WT-5800 H01US

Wireless Receiver, True Diversity, 64 Channels - WT-5800 H01US

Product Rating Product Rating Product Rating Product Rating Product Rating 0 Reviews
Write a Review
Price:
$716.00
  • Weight:
    1.54 LBS
  • Shipping:
    Calculated at Checkout

Key features

  • Color
5 Years Warranty
Sale assistant
Contact our Sales Team for a tailored experience
Adding to cart… The item has been added
?Special Order Information
Sign In for Dealer Pricing Become a BLVS Customer

Description

The wireless tuner WT-5800 is a PLL-synthesizer controlled double superheterodyne true diversity tuner to be used in UHF wireless systems. It employs a compander noise reduction circuit to minimize the influence of the ambient RF noise.

Features:

  • Automatic frequency scan
  • Integrated squelch function
  • Ideally suited for fixed installations such as in event locations, multi-purpose and sports halls, plenary and conference venues, churches, auditoriums etc.
  • System always select the stronger of the two antenna signals for further processing
  • Setup with up to 16 simultaneously operating receivers possible
  • Two antenna distribution outputs allow to simply loop through the antenna signals

Technical Specifications

Current
250mA
Voltage
12VDC
Frequency
  • 576 - 606 MHz
  • 100 Hz – 15 kHz
Channels
64CH
Distortion
0.01%
Sensitivity
16 – 40 dBμV
S/N Ratio
110dB
Operating Humidity
30 % to 85 %RH
Operating Temperature
–10°C to +50°C (14°F to 122°F)
Color
Black
Receiving System
Double Super Heterodyne
Warranty
5 Years Warranty
