Description
Features :
- Record audio with an integrated microphone
- Connect and power using PoE
- 2K (4MP) video resolution
Technical Specifications
Ambient operating humidity
0 to 90% noncondensing
Ambient operating temperature
-30 to 50º C (-22 to 122º F)
Button
Factory reset
Cable connector type
RJ45
Cable diameter
5 mm (0.2")
Cable jacket enclosure dimensions
Ø20 x 70.6 mm (0.8 x 2.8")
Cable jacket enclosure materials
- Thermoplastic elastomer
- polycarbonate
- silicone rubber
Cable jacket material
Polycarbonate
Cable length
30 cm (1 ft)
Certifications
- FCC
- IC
- CE
Dimensions
Ø90 x 71.2 mm (Ø3.5 x 2.8")
Enclosure material
- Aluminum alloy
- UV-stabilized polycarbonate
Image settings
- Color
- brightness
- sharpness
- contrast
- white balance
- exposure control
- 2DNR
- 3DNR
- NR by motion
- masking
- text overlay
LED
R/G/B/W
Lens
Fixed focal length
Max. frame rate
30 FPS
Max. power consumption
4W
Microphone
Yes (Can be disabled)
Mounting
Surface mount
Networking interface
10/100 MbE RJ45 port
Night mode
Built-in IR LED illumination and IR cut filter
Power method
PoE
Processor
Dual-core Arm® Cortex®-A7 based chip
Resistance
IK04
Resolution
4MP 2688 x 1512 (16:9)
Sensor
1/2.4" CMOS
Supported voltage range
37–57V DC
View angle
- H: 102.4°
- V: 54.9°
- D: 120.6°
Weatherproofing
IP66
Weight
330 g (11.6 oz)
Technical Specifications
Ambient operating humidity
0 to 90% noncondensing
Ambient operating temperature
-30 to 50º C (-22 to 122º F)
Button
Factory reset
Cable connector type
RJ45
Cable diameter
5 mm (0.2")
Cable jacket enclosure dimensions
Ø20 x 70.6 mm (0.8 x 2.8")
Cable jacket enclosure materials
- Thermoplastic elastomer
- polycarbonate
- silicone rubber
Cable jacket material
Polycarbonate
Cable length
30 cm (1 ft)
Certifications
- FCC
- IC
- CE
Dimensions
Ø90 x 71.2 mm (Ø3.5 x 2.8")
Enclosure material
- Aluminum alloy
- UV-stabilized polycarbonate
Image settings
- Color
- brightness
- sharpness
- contrast
- white balance
- exposure control
- 2DNR
- 3DNR
- NR by motion
- masking
- text overlay
LED
R/G/B/W
Lens
Fixed focal length
Max. frame rate
30 FPS
Max. power consumption
4W
Microphone
Yes (Can be disabled)
Mounting
Surface mount
Networking interface
10/100 MbE RJ45 port
Night mode
Built-in IR LED illumination and IR cut filter
Power method
PoE
Processor
Dual-core Arm® Cortex®-A7 based chip
Resistance
IK04
Resolution
4MP 2688 x 1512 (16:9)
Sensor
1/2.4" CMOS
Supported voltage range
37–57V DC
View angle
- H: 102.4°
- V: 54.9°
- D: 120.6°
Weatherproofing
IP66
Weight
330 g (11.6 oz)
