Description
S. Parker B9160 Heavy Duty Cylindrical Ball Knob Locks Heavy Duty Contractor Quality Cylindrical Grade 2 Locks S. Parker heavy duty cylindrical locks are available in entry, passage, privacy and storeroom/classroom functions. These locks meet ANSI-A156-2, Series 4000, Grade 2 specifications, and include SC-1 keyway #1145, or Arrow keyway K. The tumbler is a six pin keyed to five pins, and the exit from the inside is immediate, for panic-resistant use.
Features:
- All come with 2 3/4" backset. 2 3/8" backset are available on request
- The keyed sets have a deadlatch
- The locks will accept AWI or Lori plugs, and the keyed alike numbering system allows the buyer to keep and repeat the same key order for later orders.
- All parts, screws and installation instruction are included in the color coded packaging that makes stock-keeping easy.
- 3" diameter rosettes
- Strike included
Technical Specifications
Finish
Polished Brass
Backset
2-3/8"
Strike Size
4-7/8" x 1-1/4"
Handing
Field Reversible
Latch Type
Spring latch
Latch Bolt Faceplate Size
2-1/4" x 1"
Door Thickness
1-3/8"
Grade
ANSI/BHMA Grade 2
Compliance
ANSI A156.2
Latch Size
1/2 inch
Strike Plate
ASA Strike Plate
Ring Type
Trim Ring
Material
Brass Steel
Warranty
Limited Warranty
Warranty
Limited Warranty
