Description
12 VDC with Boxed Alarm
Features:
- Multi-functional control timer that operates as a door prop alarm
- Monitors whether the door has been "propped" open
- Can detect attempts to tamper with lock or door status
- Includes three 5 Amp SPDT outputs providing local and remote signaling
- Bypass mode for valid access/egress needs
- BA-DPA models come with Piezo sounder and LED
Technical Specifications
Model Numbers
- BA-DPA-12 (12 VDC)
- BA-DPA-24 (24 VDC)
Function
Door prop alarm with timed logic
Power (12 VDC)
Max 100 mA
Power (24 VDC)
Max 50 mA
Relay Outputs
3× 5 A SPDT relays
Alarm Indication
Piezo sounder + LED
Time Delay Settings
Digital adjustable 30–240 s (time 1 & 2)
Tamper Detection
Yes
Bypass Mode
Yes
Operating Temperature
32–120 °F (0–49 °C)
Material
Aluminum and steel housing
Finishing
Gray enclosure
Mounting
Surface mount
UL Compliance
- Not fire-rated
- spec not burglary rated
BAA Compliant
Yes
Warranty
Limited Lifetime Warranty
Relay #3 Feature
Monitors power interruption
Reset Method
Manual (keyswitch) or automatic via door switch
Compliance
- UL listed for alarm logic; BAA compliant
- not fire/burglar rated
Warranty
Limited Lifetime Warranty
