Description
Altronix ACMCB series distribute and switch power to access control systems and accessories. They convert a 115VAC, 60Hz input into eight (8) independently controlled 12VDC or 24VDC Class 2 Rated power-limited PTC protected outputs. Outputs are activated by an open collector sink or normally open (NO) dry trigger input from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc.
Features:
- Eight (8) independently controlled Fail-Safe and/or Fail-Secure power outputs
- Class 2 Rated power-limited PTC Protected Outputs (auto-resettable)
- Eight (8) auxiliary power outputs (unswitched)
- Filtered and electronically regulated outputs
- Supervision: - AC Fail - Battery Fail and Battery Presence
- Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the eight (8) outputs
Technical Specifications
Voltage
- Input: 115VAC
- 60Hz
- Output: 12VDC
Current
3.5A
Surge Protection
PTC 2.5A
Battery
Up to two (2) 12AH / 12VDC
Indicator
LED
Operating Temperature
0ºC to 49ºC (32ºF to 120ºF)
Operating Humidity
85% +/– 5%
BTU
12VDC: 25 BTU/Hr
Compliance
- UL294: Access Control System Units
- CSA C22.2 No.205 Signal Equipment
Warranty
Lifetime Warranty
