Description
Active Focused Infrared Request to Exit
Features:
- Designed to release or secure and monitor one electric lock
- 1/2" red LED operates on 12 or 24 VAC or VDC
- DPDT illuminated latching push button with hi-brightness built-in LED
- Switch LED operates on 12 or 24 VAC or VDC
- Switch contacts rated 3 Amps @35VDC or 120VAC
- Components mounted on standard single - four gang electrical wall plate
Technical Specifcations
Switches
4 SPDT latching/momentary
LEDs
4 built-in red & green
Contact Rating
3 A @ 35 VDC or 120 VAC
Material
Stainless steel plate
Finish
Satin-brushed stainless
Compliance
UL-rated switch stations
Gang Count
Single gang housing
Illumination Voltage
12/24 VAC/DC
Termination
22 AWG colored leads
Mounting
Surface/drywall mount
Construction Quality
Heavy-duty metal
Switch Type
SPDT latching or momentary
Warranty
Limited Lifetime Warranty
Warranty
Limited Lifetime Warranty
