Description
These MEGApix® IP cameras are NDAA compliant and deliver crystal-clear images at 4MP resolution and real-time 30fps. The bullet camera features a 2.8~12mm vari-focal lens in an IP67-rated housing. Added intelligence includes line crossing, perimeter intrusion and video tampering detection. All MEGApix® cameras are ONVIF conformant, assuring their successful integration with any open platform solution on the market.
- 4MP 1/3" image sensor at real-time 30fps
- Vari-focal lens with motorized zoom and autofocus for complete remote lens control and focused image any time
- True Wide Dynamic Range (WDR) for clear images in challenging light
- Simultaneous streaming and multiple codec options for smart bandwidth management
- 164' Smart IR™ with intelligent camera sync for clear B/W images with no need for external light
- Line crossing video analytics
- Perimeter intrusion video analytics
- Video tampering with scene-change detection video analytics
- Video tampering with video-blur detection video analytics
- Video tampering with abnormal color detection video analytics
- Smart DNR™ 3D digital noise reduction reduces noise and ghosting for motion in low-light environments.
- Privacy zones cover sensitive areas in the camera's field of view.
- Backlight compensation (BLC)
- Built-in microphone and audio input for direct communication between the monitoring station and the camera's location
- Local SD card slot for local recording in case of network loss
- Web server built-in for easy camera management from any browser
- PoE and DC12V for single cable simplified installation
- NDAA compliant for federal and government projects
- IP67-rated camera housing built to last
- 5 year warranty
Technical Specifications
Total Pixels
2560 (H) x 1440 (V)
Image Sensor
4MP 1/3" CMOS sensor (x4)
Maximum Resolution
4MP
Minimum Scene Illumination - color
- 0.0 lux (B/W)
- 0.005 lux (color)
Focal Length
2.8mm ~ 12mm
Horizontal Field of View (HFOV)
92°~31°
Illumination Distance
164' range Smart IR
Lens Type
Vari-focal Lens
Vertical Field of View (VFOV)
48°~17.2°
Audio Compression
G.711A / U
3D digital noise reduction
Smart DNR™ 3D Digital Noise Reduction
Auto gain control
Auto
Camera Analytics
- Line Crossing
- Perimeter Intrusion
- video Tampering Detection (Scene Change
- Video Blur
- Abnormal Color Detection)
Day and night
- Auto day/night
- Day (color)
- Night (B/W)
De-fog
Yes
Memory Slot
- Micro SD/SDHC/SDXC class 10 card (card not included)
- Up to 1TB micro SD / FAT32
Mirror/flip
Yes
Motion Detection
Yes
Operational Notifications
- FTP server
Privacy Zones
8 programmable privacy masks
Sharpness
Yes
Shutter Mode
- Auto
- Manual
Shutter Speed
1/2s ~ 1/100000s
White Balance
Yes
Wide Dynamic Range (WDR)
True WDR 120dB
IP
- IPv4
- IPv6
LAN
802.3 compliance 10/100 LAN
Network Resolution
- 4MP
- 3MP
- 2.1MP/1080P
- 720P
- D1
- 480×240
- CIF (60Hz: 1 ~ 30fps; 50Hz: 1~25fps)
Protocol
- 802.1x
- DDNS
- DHCP
- FTP
- HTTP
- HTTPs
- ICMP
- IGMP
- NTP
- ONVIF
- PPPoE
- QoS
- RTCP
- RTP
- RTSP
- SMTP
- SNMP
- UDP
- UPnP
Security
- Digest authentication (ID/PW)
- IP filtering
- MAC filtering
Stream Speed
Up to 30fps at all resolutions
Video Compression Type
- H.264
- H.265
- MJPEG
Video Management Software
- Any ONVIF conformant CMS
- DW Spectrum® IPVMS
Environmental Operating Humidity
0-95% RH (non–condensing)
Environmental Operating Temperature
-22°F ~ 140°F (-30°C ~ 60°C)
Camera Dimensions (H X W X D)
- Dimensions based on the position of the sun shield cover
- 8.69" x 3.16" x 2.77" (220.8 x 80.5 x70.6 mm)
Camera Weight
1.52 lbs (0.69 kg)
Housing
Bullet
IK Rating
IK10 impact-resistant
IP Rating
Weather Resistant (IP67)
Materials
Aluminum die-casting
Power Consumption
- DC12V: max 8.0W
- 666.6mA
- PoE: max 8.0W
Power Requirements
- Adapter not included
- PoE
Warranty
5 Year Warranty
Certifications
- FCC
- CE
- ROHS
- ONVIF
- NDAA
Warranty
5 Year Warranty
