Description
purpose-built Nyquist appliance accessories are available to help simplify system installations. Please note that all Nyquist appliances ship with mounting ears that can be used in wall-mount and rubber feet for shelf-mount applications.
Features:
- PoE Class no local power required, .3af compliant.
- deployment for easy installation.
- Based noise rejection and voice bandwidth optimization.
- digital microphone for superior talkback audio.
- deployment for easy installation.
- Bus 2.0 Interface connects to Nyquist Digital Call Switches ().
Technical Specifications
Ethernet Port
10/100 Connection
PoE Port
Class 3
Contact Type
Form-C SPDT type 2A 30V
Mount Type
- Flush Mount
- Surface Mount
Material
- Powder coated steel back box
- plastic injection molded front bezel
Operating Temperature
32°F to 100°F non-condensing
Flash Pattern
- Amber Blue Green Orange
- Red Violet White Yellow
Frequency
95Hz-20kHz
Sensitivity
94 dB (1W @ 1m on axis)
Dispersion
110°
Compliance
- UL62368-1
- EN55032
- EN55035
- 802.3af compliant
