Description
purpose-built Nyquist appliance accessories are available to help simplify system installations. Please note that all Nyquist appliances ship with mounting ears that can be used in wall-mount and rubber feet for shelf-mount applications.
Features:
- PoE Class no local power required, .3af compliant.
- deployment for easy installation.
- Based noise rejection and voice bandwidth optimization.
- digital microphone for superior talkback audio.
- deployment for easy installation.
- Bus 2.0 Interface connects to Nyquist Digital Call Switches ().
Technical Specifications
Compliance
UL62368-1, EN55032, EN55035, 802.3af compliant
Contact Type
Form-C SPDT type 2A 30V
Dispersion
110°
Ethernet Port
10/100 Connection
Flash Pattern
Amber Blue Green Orange, Red Violet White Yellow
Frequency
95Hz-20kHz
Material
Powder coated steel back box, plastic injection molded front bezel
Mount Type
Flush Mount, Surface Mount
Operating Temperature
32°F to 100°F non-condensing
PoE Port
Class 3
Sensitivity
94 dB (1W @ 1m on axis)
