Description
Door Position Switch
Features:
- Fire rated—3 hours
- All ferrous metal surfaces plated to MIL specification
- Architectural brushed stainless steel finish (US32D/630)
- Dress Covers available
- Fully sealed electronics - tamper and weather resistant
- Hardware accessories available to configure any opening
Technical Specifications
Applications
Indoor/outdoor traffic control
Bond Sensor Option
BondSTAT available (models B/BD)
Cable
10 ft (3.05 m) jacketed, stranded conductor
Compliance
UL 10C, CAN4-S104, UL 294, CSA-C22.2 No.205
Current Draw 12 V
300 mA
Current Draw 24 V
150 mA
DPS Option
Door Position Switch available (D/BD)
Design Feature
Collapsing blind nuts for strength
Dimensions (L×D×H)
8?×1 5/8?×1 7/8? (203×41×48 mm)
Energy Efficient
Low power usage
Finish Durability
All ferrous surfaces plated to MIL spec
Finishing
Brushed stainless (US32D/630)
Holding Force
600 lbs (272 kg)
Material
Ferrous metal base (steel), stainless steel housing
Mounting
Surface-mounted with blind nuts
Noise Suppression
Included MOV
Operating Temp
–40 °F to +140 °F (–40 °C to +60 °C)
Residual Magnetism
Instant-release circuit, no residual magnetism
Safety
UL fire-rated (3 hr)
Seal Rating
Fully sealed electronics (tamper/weatherproof)
Strike Dimensions
6 1/4?×1/2?×1 5/8?
Voltage
12/24 VDC automatic dual-voltage
Warranty
Limited Lifetime Warranty
